TungMeister Testina intercambiabile

Pagina iniziale / PRODOTTI / Milling / TungMeister Testina intercambiabile
product_Milling_TungMeister

TungMeister – Programma di fresatura integrale a testine intercambiabili, risparmio nei tempi di cambio utensile

Scegli la miglior combinazione stelo-testina tra le moltissime opzioni disponibili!
Riduci al minimo il tempo di setup ed aumenta la produttività.

Applicazioni e Caratteristiche

Applicazioni

Shoulder millingShoulder milling RFace millingSlottingSlotting RSide slottingSide millingPocketingRampingProfilingPlungingHole enlargingHolemakingCounterboringHole chamferingChamferingExternal thread millingInternal Thread milling

Caratteristiche

1. Vasta gamma di geometrie di taglio

• L’offerta comprende 45 tipi diversi di geometrie di taglio. La sostituzione della testina è semplice e la ripetibilità è assicurata dal filetto di accoppiamento preciso.

2. Steli disponibili in tre materiali diversi

• L’utilizzatore è in grado di scegliere la miglior combinazione possibile secondo i propri parametri di lavorazione, lunghezza operativa ed applicazione richiesta.

3. No setup time

Il tempo di fermo macchina viene ridotto al minimo, necessario soltanto per sostituire la testina.

4. Elevata precisione e ripetibilità

Ripetibilità e precisione sono garantite dall’accoppiamento testina-stelo a doppia faccia di contatto tra la parte conica e quella piana.

Geometrie e gradi in metallo duro

Testine

Testine per spallamento retto

Testine per spianatura

Testine per alto avanzamento

Testine a profilo sferico

Testine a profilo torico

Testine coniche a barile

Testine per centratura e smussi

Testine per smussatura

Testine per centratura

Testine per svasatura

Testine per scanalatura

Testine per filettatura

Gradi in metallo duro

AH735

  • Rivestimento PVD nano-multistrato
  • Priorità resistenza alla frattura e alla scheggiatura

AH715

  • Rivestimento PVD nano-multistrato
  • Priorità resistenza all’usura, vita utensile maggiore

GH130

  • Elevata resistenza alla scheggiatura e alla frattura
  • Ideale per acciai, acciai inossidabili e ghisa

GH730

  • Good balance between wear and chipping resistance
  • First choice for slotting of various materials

Steli

Steli

Codolo a gambo cilindrico scaricato

Codolo a gambo cilindrico scaricato, colletto con foro per lubrificazione

Codolo a gambo cilindrico attacco Weldon

Codolo ad alta rigidità

Codolo a gambo cilindrico e colletto conico

Codolo a gambo cilindrico e colletto conico con foro per lubrificazione

Esempi di lavorazione

Esempio #1
Pezzo: Ingranaggio
Materiale: 18CrMo4 / SCM420
Stelo: VSSD16L100S10-S (Acciaio, ø16 mm)
Testina: VEE160L12.0C60I04S10 (ø16 mm)
Grado: AH715
Parametri di taglio: Vc = 100 (m/min)
fz = 0.09 (mm/dente)
ap = 10 (mm)
ae = 0.1 (mm)
Refrigerante: sì
Esempio #2
Pezzo: Albero
Materiale: C45 / S45C
Stelo: VSSD10L075S06-S (Acciaio, ø10 mm)
Testina: VEH100L15.0R10I04S06 (ø10 mm)
Grado: AH715
Parametri di taglio: Vc = 100 (m/min)
fz = 0.05 (mm/dente)
ap = 1 (mm)
ae = 6 (mm)
Refrigerante: sì
Esempio #3
Pezzo: Rastrelliera
Materiale: 42CrMo4 / SCM440
Stelo: VSSD25L075S12-S (Acciaio, ø25 mm)
Testina: VEH200L30.0R05I04S12 (ø20 mm)
Grado: AH715
Parametri di taglio: Vc = 140 (m/min)
fz = 0.08 (mm/dente)
ap = 24 (mm)
ae = 5.5 (mm)
Refrigerante: sì

Parametri di taglio standard

Fresatura di spallamento retto
VEH, VEE: 3 taglienti, VED / VEE: 4 taglienti, VEE-A, VEE-I, VEE-R, VED-R, VEE-C
ISO Materiale da lavorare Durezza Velocità di taglio Vc (m/min) Avanzamento dente: fz (mm/dente) Prof. di taglio
ap (mm)		 Largh. di taglio
ae (mm)
Diametro fresa: DC (mm)
5 6 8 10 12 16 20 25 32
Acciai al carbonio
S45C, S55C, ecc.
C45, C55, ecc.		 – 300 HB 80 – 180 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Acciai legati
SCM440, SCr420, ecc.
42CrMo4, 20Cr4, ecc.		 – 300 HB 60 – 140 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Acciai pretempra
PX5, NAK80, ecc.		 30 – 40 HRC 60 – 120 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Acciai inossidabili
SUS304, SUS316, ecc.
X5CrNi18-9, X5CrNiMo17-12-2, ecc.		 – 200 HB 40 – 100 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Ghisa grigia
FC250, FC300,
250, 300,  GG250, GG300, ecc.		 150 – 250 HB 80 – 200 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Ghisa sferoidale
FCD450,
450-10S,  GGG450, ecc.		 150 – 250 HB 80 – 200 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Leghe di alluminio
Si < 13%		 – 200 – 700 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Leghe di alluminio
Si ≥ 13%		 – 100 – 300 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Leghe di titanio
Ti-6Al-4V, ecc.		 – 40 – 80 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Leghe resistenti al calore
Inconel 718, ecc.		 – 20 – 40 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Acciai temprati
SKD6, SKT4, ecc.
55NiCrMoV7, ecc.		 40 – 50 HRC 40 – 80 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
Acciai temprati
SKD11, SKH51, ecc.
HS6-5-2, ecc.		 50 – 60 HRC 20 – 60 0.03 – 0.07 0.03 – 0.07 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.1 – 0.18 0.6 x DC 0.25 x DC
VED / VEE: 6 taglienti, VED / VEE: 8, 10 taglienti, VED: 7, 9 taglienti
ISO Materiale da lavorare Durezza Velocità di taglio
Vc (m/min)		 Avanzamento dente: fz (mm/dente) Prof. di taglio
ap (mm)		 Largh. di taglio
ae (mm)
Diametro fresa: DC (mm)
8 10 12 16 20 25
Leghe di titanio
Ti-6Al-4V, ecc.		 – 60 – 120 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.6 x DC 0.02 x DC
Leghe resistenti al calore
Inconel 718, ecc.		 – 30 – 60 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.6 x DC 0.02 x DC
Acciai temprati
SKD6, SKT4, ecc.
55NiCrMoV7, ecc.		 40 – 50 HRC 80 – 160 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.6 x DC 0.02 x DC
Acciai temprati
SKD11, SKH51, ecc.
HS6-5-2, ecc.		 50 – 60 HRC 40 – 90 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 0.6 x DC 0.02 x DC
Esecuzione cave
VEH, VEE: 3 flutes, VED/VEE: 4 flutes, VEE-A, VEE-I, VEE-R, VEE-C
ISO Workpiece material Hardness Cutting speed Vc (m/min) Feed per tooth: fz (mm/t) Depth of cut ap (mm)
Tool diameter: DC (mm)
5 6 8 10 12 16 20 25 32
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 50 – 70 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 40 – 80 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 40 – 70 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 30 – 60 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 50 – 120 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 50 – 120 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Aluminium alloys
Si < 13%		 – 130 – 400 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Aluminium alloys
Si ≥ 13%		 – 70 – 200 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Titanium alloys
Ti-6Al-4V, etc.		 – 40 HRC 20 – 40 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Heat-resistant alloys
Inconel 718, etc.		 – 40 HRC 10 – 20 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 25 – 60 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 10 – 30 0.03 – 0.04 0.03 – 0.04 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.07 – 0.1 0.07 – 0.1 0.5 x DC
Spianatura
VFM
ISO Workpiece material Hardness Cutting speed Vc (m/min) Feed per tooth: fz (mm/t) Depth of cut ap (mm) Width of cut ae(mm)
Tool diameter: DC (mm)
12 16 20 25
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 80 – 180 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 60 – 140 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 60 – 120 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 40 – 100 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 80 – 200 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 80 – 200 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Aluminium alloys
Si < 13%		 – 200 – 700 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Aluminium alloys
Si ≥ 13%		 – 100 – 300 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Titanium alloys
Ti-6Al-4V, etc.		 – 40 – 80 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Heat-resistant alloys
Inconel 718, etc.		 – 20 – 40 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 40 – 80 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 20 – 60 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.1 – 0.17 1 0.7 x DC
Fresatura ad alto avanzamento
VFX: 2, 4, 6 taglienti
ISO Workpiece material Hardness Cutting speed Vc (m/min) ø10 ø12 ø16 ø20 Width of cut
ae (mm)
Feed per tooth
fz (mm/t)		 Depth of cut
ap (mm)		 Feed per tooth
fz (mm/t)		 Depth of cut
ap (mm)		 Feed per tooth
fz (mm/t)		 Depth of cut
ap (mm)		 Feed per tooth
fz (mm/t)		 Depth of cut
ap (mm)
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 100 – 200 0.3 – 0.7 0.5 0.4 – 0.8 0.5 0.5 – 0.9 0.75 0.6 – 1 1 0.6 x DC
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 80 – 180 0.2 – 0.6 0.5 0.3 – 0.7 0.5 0.4 – 0.8 0.75 0.5 – 0.9 1 0.6 x DC
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 80 – 160 0.2 – 0.5 0.4 0.2 – 0.5 0.4 0.3 – 0.6 0.5 0.3 – 0.6 0.75 0.6 x DC
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 60 – 100 0.2 – 0.6 0.4 0.2 – 0.6 0.4 0.3 – 0.7 0.5 0.3 – 0.7 0.75 0.6 x DC
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 100 – 220 0.3 – 0.7 0.5 0.4 – 0.8 0.75 0.5 – 0.9 0.75 0.6 – 1 1 0.6 x DC
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 100 – 220 0.2 – 0.6 0.5 0.3 – 0.7 0.75 0.4 – 0.8 0.75 0.5 – 0.9 1 0.6 x DC
Titanium alloys
Ti-6Al-4V, etc.		 – 40 – 80 0.2 – 0.5 0.4 0.2 – 0.5 0.4 0.2 – 0.6 0.5 0.2 – 0.6 0.5 0.25 x DC
Heat-resistant alloys
Inconel 718, etc.		 – 20 – 40 0.1 – 0.3 0.3 0.1 – 0.3 0.3 0.1 – 0.3 0.4 0.1 – 0.3 0.4 0.25 x DC
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 40 – 80 0.2 – 0.4 0.3 0.2 – 0.4 0.3 0.3 – 0.5 0.4 0.3 – 0.5 0.4 0.45 x DC
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 20 – 60 0.1 – 0.2 0.2 0.1 – 0.2 0.2 0.1 – 0.3 0.3 0.1 – 0.3 0.3 0.25 x DC

Please note that the feed per tooth should not exceed the maximum feed per tooth for each product.

Profilo sferico - Copiatura (sgrossatura)
VBB-BM / BG / SG, VBD-BG, VBE-BGA
ISO Workpiece material Hardness Cutting speed Vc (m/min) Feed per tooth: fz (mm/t) Depth of cut ap (mm) Pick feed
Pf (mm)
Tool diameter: DC (mm)
5 6 8 10 12 16 20 25
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 100 – 200 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.4 x DC
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 80 – 180 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.4 x DC
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 80 – 160 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.4 x DC
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 60 – 100 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.4 x DC
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 100 – 220 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.4 x DC
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 100 – 220 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.4 x DC
Aluminium alloys
Si < 13%		 – 200 – 700 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.4 x DC
Aluminium alloys
Si ≥ 13%		 – 100 – 300 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.4 x DC
Titanium alloys
Ti-6Al-4V, etc.		 – 40 – 80 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.2 x DC
Heat-resistant alloys
Inconel 718, etc.		 – 20 – 40 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.2 x DC
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 40 – 80 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.2 x DC
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 20 – 60 0.03 – 0.07 0.03 – 0.07 0.04 – 0.08 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.08 – 0.15 0.08 – 0.15 0.3 x DC 0.2 x DC
Profilo sferico - Copiatura (semi-finitura e finitura)
VBB-BM / BG / SG, VBD-BG, VBE-BGA
ISO Workpiece material Hardness Cutting
speed
Vc
(m/min)		 Feed per tooth: fz (mm/t) Depth of cut
ap (mm)		 Pick feed
Pf (mm)
Tool diameter: DC (mm)
5 6 8 10 12 16 20 25
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 120 – 250 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.1 x DC 0.15 x DC
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 100 – 220 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.1 x DC 0.15 x DC
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 100 – 200 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.1 x DC 0.15 x DC
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 80 – 120 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.1 x DC 0.15 x DC
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 120 – 280 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.1 x DC 0.15 x DC
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 120 – 280 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.1 x DC 0.15 x DC
Aluminium alloys
Si < 13%		 – 300 – 1000 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.1 x DC 0.15 x DC
Aluminium alloys
Si ≥ 13%		 – 150 – 400 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.1 x DC 0.15 x DC
Titanium alloys
Ti-6Al-4V, etc.		 – 50 – 100 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.08 x DC 0.1 x DC
Heat-resistant alloys
Inconel 718, etc.		 – 30 – 50 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.08 x DC 0.1 x DC
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 50 – 100 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.08 x DC 0.1 x DC
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 30 – 80 0.04 – 0.09 0.04 – 0.09 0.06 – 0.11 0.07 – 0.12 0.08 – 0.13 0.09 – 0.16 0.1 – 0.18 0.1 – 0.18 0.08 x DC 0.1 x DC
Torica - Fresatura di spallamento
VRB, VRC, VRD
ISO Workpiece material Hardness Cutting speed Vc (m/min) Feed per tooth: fz (mm/t) Depth of cut
ap (mm)		 Width of cut
ae(mm)
Tool diameter: DC (mm)
8 10 12 16 20
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 80 – 180 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 60 – 140 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 60 – 120 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 40 – 100 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 80 – 200 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 80 – 200 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Aluminium alloys
Si < 13%		 – 200 – 700 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Aluminium alloys
Si ≥ 13%		 – 100 – 300 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Titanium alloys
Ti-6Al-4V, etc.		 – 40 – 80 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Heat-resistant alloys
Inconel 718, etc.		 – 20 – 40 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 40 – 80 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 20 – 60 0.05 – 0.09 0.07 – 0.12 0.08 – 0.13 0.09 – 0.15 0.1 – 0.17 0.6 x DC 0.25 x DC
Torica - Esecuzione cave
VRB, VRC, VRD
ISO Workpiece material Hardness Cutting speed Vc (m/min) Feed per tooth: fz (mm/t) Depth of cut
ap (mm)
Tool diameter: DC (mm)
8 10 12 16 20
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 50 – 70 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 40 – 80 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 40 – 70 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 30 – 60 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 50 – 120 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 50 – 120 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Aluminium alloys
Si < 13%		 – 130 – 400 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Aluminium alloys
Si ≥ 13%		 – 70 – 200 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Titanium alloys
Ti-6Al-4V, etc.		 – 20 – 40 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Heat-resistant alloys
Inconel 718, etc.		 – 10 – 20 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 25 – 60 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 10 – 30 0.03 – 0.04 0.04 – 0.05 0.05 – 0.06 0.06 – 0.08 0.07 – 0.1 0.5 x DC
Profilo a barile, Bull nose, Lente - Copiatura
VBO, VBN, VBL
ISO Workpiece material Hardness Cutting speed Vc (m/min) Feed per tooth: fz (mm/t) Cusp height (mm)
Tool diameter: DC (mm)
10 12 16
Low carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 100 – 200 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
High carbon steel
SCM440, SCr415, etc.
42CrMo4, 15Cr3, etc.		 – 300 HB 80 – 180 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 80 – 160 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 60 – 100 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Grey cast iron
FC250, FC300, etc.
250, 300, etc.		 150 – 250 HB 100 – 220 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Ductile cast iron
FCD400, etc.
400-15S, etc.		 150 – 250 HB 100 – 220 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Aluminium alloys
Si < 13%		 – 200 – 700 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Aluminium alloys
Si ≥13%		 – 100 – 300 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Titanium alloys
Ti-6Al-4V, etc.		 – 40 – 80 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Heat-resistant alloys
Inconel718, etc.		 50 – 60 HRC 20 – 40 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Hardened steel
SKD61, SKT4, etc.
X40CrMoV5-1, 55NiCrMoV6, etc.		 – 40 – 80 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Hardened steel
SKD11, SKH, etc.
X153CrMoV12, HS18-0-1, etc.		 50 – 60 HRC 20 – 60 0.05 – 0.1 0.06 – 0.11 0.07 – 0.13 0.1
Smussatura e svasatura (Fresatura, smussatura Z-feed)
VCA, VCW, VCR
ISO Workpiece material Hardness Cutting speed
Vc (m/min)		 Feed per tooth
fz (mm/t)
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 60 – 100 0.03 – 0.06
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 50 – 80 0.03 – 0.06
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 40 – 70 0.03 – 0.06
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 30 – 50 0.03 – 0.06
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 80 – 120 0.03 – 0.06
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 80 – 120 0.03 – 0.06
Aluminium alloys – 100 – 200 0.04 – 0.08
Titanium alloys
Ti-6Al-4V, etc.		 – 30 – 50 0.025 – 0.05
Heat-resistant alloys
Inconel 718, etc.		 – 20 – 40 0.02 – 0.04
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 30 – 50 0.025 – 0.05
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 20 – 40 0.02 – 0.04
Spot drill
VCP, VDS
ISO Workpiece material Hardness Cutting speed
Vc (m/min)		 Feed
f (mm/rev)
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 60 – 100 0.06 – 0.12
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 50 – 80 0.06 – 0.12
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 40 – 70 0.06 – 0.12
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 30 – 50 0.06 – 0.12
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 80 – 120 0.06 – 0.12
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 80 – 120 0.06 – 0.12
Aluminium alloys – 100 – 200 0.08 – 0.16
Titanium alloys
Ti-6Al-4V, etc.		 – 30 – 50 0.05 – 0.1
Heat-resistant alloys
Inconel 718, etc.		 – 20 – 40 0.04 – 0.08
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 30 – 50 0.05 – 0.1
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 20 – 40 0.04 – 0.08
Centratura
VDP
ISO Workpiece material Hardness Cutting speed Vc (m/min) Feed : f (mm/rev)
VDP107 VDP165 VDP2 VDP3 VDP4 VDP5 VDP6
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 40 – 80 0.02 – 0.04 0.025 – 0.05 0.025 – 0.05 0.04 – 0.08 0.05 – 0.1 0.05 – 0.1 0.06 – 0.12
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 30 – 50 0.02 – 0.04 0.025 – 0.05 0.025 – 0.05 0.04 – 0.08 0.05 – 0.1 0.05 – 0.1 0.06 – 0.12
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 20 – 30 0.02 – 0.04 0.025 – 0.05 0.025 – 0.05 0.04 – 0.08 0.05 – 0.1 0.05 – 0.1 0.06 – 0.12
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 15 – 25 0.015 – 0.03 0.02 – 0.04 0.02 – 0.04 0.04 – 0.08 0.05 – 0.1 0.05 – 0.1 0.06 – 0.12
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 60 – 100 0.02 – 0.04 0.025 – 0.05 0.025 – 0.05 0.05 -0.09 0.07 – 0.012 0.07 – 0.12 0.12 – 0.18
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 60 – 100 0.02 – 0.04 0.025 – 0.05 0.025 – 0.05 0.04 – 0.08 0.05 – 0.1 0.05 – 0.1 0.1 – 0.15
Titanium alloys
Ti-6Al-4V, etc.		 – 15 – 25 0.01 – 0.02 0.01 – 0.02 0.015 – 0.03 0.04 – 0.07 0.04 – 0.07 0.04 – 0.07 0.04 – 0.07
Heat-resistant alloys
Inconel 718, etc.		 – 10 – 20 0.01 – 0.02 0.01 – 0.02 0.015 – 0.03 0.03 – 0.06 0.03 – 0.06 0.03 – 0.06 0.03 – 0.06
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 15 – 25 – – – 0.04 – 0.07 0.04 – 0.07 0.04 – 0.07 0.04 – 0.07
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 10 – 20 – – – 0.03 – 0.06 0.03 – 0.06 0.03 – 0.06 0.03 – 0.06

—0.03 – 0.060.03 – 0.060.03 – 0.060.03 – 0.06

Svasatura
VGC
ISO Workpiece material Hardness Cutting speed
Vc (m/min)		 Feed per tooth
fz (mm/t)
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 40 – 80 0.04 – 0.08
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 30 – 50 0.04 – 0.08
Prehardened steel
PX5, NAK80, etc.		 30 – 40 HRC 20 – 30 0.04 – 0.08
Stainless steel
SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 15 – 25 0.04 – 0.08
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 60 – 100 0.05 – 0.09
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 60 – 100 0.04 – 0.08
Titanium alloys
Ti-6Al-4V, etc.		 – 15 – 25 0.04 – 0.07
Heat-resistant alloys
Inconel 718, etc.		 – 10 – 20 0.03 – 0.06
Hardened steel
SKD6, SKT4, etc.
55NiCrMoV7, etc.		 40 – 50 HRC 15 – 25 0.04 – 0.07
Hardened steel
SKD11, SKH51, etc.
HS6-5-2, etc.		 50 – 60 HRC 10 – 20 0.03 – 0.06

When drilling, pecking operation should be applied with the depth of 0.3 – 0.5 mm per step.
Apply the same cutting conditions as the VEE type head when conducting shoulder milling or slotting operations.

Esecuzione cave
ISO Workpiece material Hardness VST VTB
Cutting speed
Vc (m/min)		 Feed per tooth
fz (mm/t)		 Cutting speed
Vc (m/min)		 Feed per tooth
fz (mm/t)
Carbon steel
S45C, S55C, etc.
C45, C55, etc.		 – 300 HB 80 – 180 0.05 – 0.15 80 – 180 0.08 – 0.18
Alloy steel
SCM440, SCr420, etc.
42CrMo4, 20Cr4, etc.		 – 300 HB 60 – 120 0.04 – 0.12 60 – 120 0.05 – 0.15
Stainless steel SUS304, SUS316, etc.
X5CrNi18-9, X5CrNiMo17-12-2, etc.		 – 200 HB 50 – 120 0.04 – 0.12 50 – 120 0.05 – 0.15
Grey cast iron
FC250, FC300, etc.
250, 300, etc., GG250, GG300, etc.		 150 – 250 HB 100 – 200 0.05 – 0.15 100 – 200 0.08 – 0.18
Ductile cast iron
FCD450, etc.
450-10S, etc., GGG450, etc.		 150 – 250 HB 100 – 200 0.04 – 0.12 100 – 200 0.05 – 0.15
Aluminium alloys
Si < 13%		 – 200 – 600 0.05 – 0.15 200 – 600 0.08 – 0.18
Aluminium alloys
Si ≥ 13%		 – 100 – 300 0.03 – 0.13 100 – 300 0.05 – 0.15
Titanium alloys
Ti-6Al-4V, etc.		 – 40 – 60 0.04 – 0.12 40 – 60 0.05 – 0.15
Heat-resistant alloys
Inconel 718, etc.		 – 15 – 35 0.02 – 0.1 15 – 35 0.02 – 0.1
Testine di fresatura ad inserti
HPAV06-S
ISO Workpiece materials Hardness Priority Grades Cutting speed Vc (m/min) Feed per tooth
fz (mm/t)
Low carbon steel
S15C / C15E4, SS400 / E275A, etc.		 – 200 HB First choice AH3225 230 – 430 0.07 – 0.12
Carbon steel and alloy steel
S55C / C55, SCM440 / 42CrMo4, etc.		 – 300 HB First choice AH3225 150 – 350 0.07 – 0.12
Prehardend steel
NAK80, PX5, etc.		 30 – 40 HRC First choice AH3225 100 – 230 0.07 – 0.12
Stainless steel
SUS304 / X5CrNi18-9,
SUS316 / X5CrNiMo17-12-3, etc.		 – First choice AH3135 150 – 220 0.06 – 0.1
Grey cast iron
FC250 / 250, FC300 / 300, etc.		 150 – 250 HB First choice AH120 200 – 330 0.07 – 0.12
Ductile cast iron
FCD400, FCD600 / 600-3, etc.		 150 – 250 HB First choice AH120 150 – 240 0.07 – 0.12
Aluminium alloys
Si < 13%		 – First choice KS05F 650 – 1000 0.07 – 0.12
Aluminium alloys
Si ≥ 13%		 – First choice KS05F 100 – 230 0.04 – 0.12
Titanium alloys
Ti-6AI-4V, etc.		 – First choice AH130 40 – 90 0.04 – 0.1
Superalloys
Inconel718, etc.		 – First choice AH130 45 – 65 0.04 – 0.09
Hardened steel SKD61 /
X40CrMoV5-1, etc.		 40 – 50 HRC First choice AH120 45 – 70 0.04 – 0.08
SKD11 /
X153CrMoV12, etc.		 50 – 60 HRC First choice AH120 40 – 65 0.04 – 0.06
Filettatura
VMT, VTR
ISO Material Condition Tensile strength [N/mm2] Hardness
HB		 Cutting speed
(m/min)		 Tool dia. (mm)
Feed (mm/t)
AH725 ø10 ø12 ø15.4, ø15.7, ø16 ø21.7
Non-alloy steel and cast steel, free cutting steel < 0.25 %C Annealed 420 125 100 – 250 0.08 0.09 0.12 0.15
≥ 0.25 %C Annealed 650 190 80 – 210 0.08 0.09 0.12 0.15
< 0.55 %C Quenched and tempered 850 250 65 – 170
≥ 0.55 %C Annealed 750 220 110 – 180 0.07 0.08 0.1 0.12
Quenched and tempered 1000 300 95 – 160 0.07 0.08 0.1 0.12
Low alloy steel and cast steel
(less than 5% of alloying elements)		 Annealed 600 200 90 – 160 0.05 0.05 0.07 0.08
Quenched and tempered 930 275 65 – 200 0.05 0.05 0.07 0.08
1000 300 70 – 210 0.05 0.05 0.07 0.08
1200 350 95 – 160 0.05 0.05 0.07 0.08
High alloyed steel, cast steel, and tool steel Annealed 680 200 130 – 170 0.05 0.05 0.07 0.08
Quenched and tempered 1100 325 75 – 100 0.05 0.05 0.07 0.08
Stainless steel and cast steel Ferritic/martensitic 680 200 110 – 170 0.05 0.05 0.07 0.08
Martensitic 820 240 70 – 155 0.05 0.05 0.07 0.08
Stainless steel Annealed 600 180 85 – 100 0.05 0.05 0.07 0.08
Cast iron nodular (GGG) Ferritic/martensitic 180 120 – 160 0.08 0.09 0.12 0.15
Pearlitic 260 75 – 160 0.08 0.09 0.12 0.15
Grey cast iron (GG) Ferritic 160 70 – 150 0.08 0.09 0.12 0.15
Pearlitic 250 110 – 140 0.08 0.09 0.12 0.15
Malleable cast iron Ferritic 130 120 – 160 0.08 0.09 0.12 0.15
Pearlitic 230 110 – 140 0.08 0.09 0.21 0.15
Aluminium-wrought alloy Not cureable 60 160 – 300 0.08 0.09 0.12 0.15
Cured 100
Aluminium-cast, alloyed ≤12% Si Not cureable 75 150 – 350 0.08 0.09 0.12 0.15
Cured 90
>12% Si High temperature 130 100 – 250 0.05 0.05 0.07 0.08
Copper alloys >1% Pb Free cutting 110
Brass 90
Electrolitic copper 100
Non-metallic Duroplastics, fiber plastics 100 – 400 0.11 0.12 0.15 0.18
Hard rubber
High temp. alloys Fe based Annealed 200
Cured 280
Ni or Co based Annealed 250 20 – 80 0.03 0.03 0.04 0.04
Cured 350
Cast 320
Titanium Ti alloys RM 400
Alpha+beta alloys cured RM 1050 20 – 80 0.03 0.03 0.04 0.04
Hardened steel Hardened 55 HRC 55 – 65
Hardened 60 HRC 45 – 55
Chilled cast iron Cast 400 90 – 105
Cast iron Hardened 55 HRC 55 – 65

Per maggiori informazioni su questo prodotto, visita il nostro e-catalog oppure scarica la brochure completa:

e-Catalog

Metric

PDF
Online Shop

Negozio online

Negozio online
Acquista online

Scopri di più
e-Catalog

e-Catalog

e-Catalog
Scarica disegni CAD e modelli 3D

Scopri di più
Risorse
